- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionMOSFET N-CH 100V 17.5/140A TO262
- CategoryTransistors - FETs, MOSFETs - Single
- Datasheet AOW290 Datasheet
-
ECAD Model
- Share
In Stock: 198
Can ship immediately
Pricing:
Call for price or sumbit a RFQ
Quote It
Technical Details
- Series:-
- Package:Tube
- Part Status:Obsolete
- FET Type:N-Channel
- Technology:MOSFET (Metal Oxide)
- Drain to Source Voltage (Vdss):100 V
- Current - Continuous Drain (Id) @ 25°C:17.5A (Ta), 140A (Tc)
- Drive Voltage (Max Rds On, Min Rds On):10V
- Rds On (Max) @ Id, Vgs:3.2mOhm @ 20A, 10V
- Vgs(th) (Max) @ Id:4.1V @ 250µA
- Gate Charge (Qg) (Max) @ Vgs:126 nC @ 10 V
- Vgs (Max):±20V
- Input Capacitance (Ciss) (Max) @ Vds:7180 pF @ 50 V
- FET Feature:-
- Power Dissipation (Max):1.9W (Ta), 500W (Tc)
- Operating Temperature:-55°C ~ 175°C (TJ)
- Mounting Type:Through Hole
- Supplier Device Package:TO-262
- Package / Case:TO-262-3 Long Leads, I²Pak, TO-262AA
