IRFH7191TRPBF
IR (Infineon Technologies)
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionMOSFET N-CH 100V 15A/80A PQFN
- CategoryTransistors - FETs, MOSFETs - Single
- Datasheet IRFH7191TRPBF Datasheet
-
ECAD Model
- Share
In Stock: 142
Can ship immediately
Pricing:
- 1$1.12444
- 4,000$1.12444
Quote It
Technical Details
- Series:FASTIRFET™, HEXFET®
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Obsolete
- FET Type:N-Channel
- Technology:MOSFET (Metal Oxide)
- Drain to Source Voltage (Vdss):100 V
- Current - Continuous Drain (Id) @ 25°C:15A (Ta), 80A (Tc)
- Drive Voltage (Max Rds On, Min Rds On):10V
- Rds On (Max) @ Id, Vgs:8mOhm @ 48A, 10V
- Vgs(th) (Max) @ Id:3.6V @ 100µA
- Gate Charge (Qg) (Max) @ Vgs:39 nC @ 10 V
- Vgs (Max):±20V
- Input Capacitance (Ciss) (Max) @ Vds:1685 pF @ 50 V
- FET Feature:-
- Power Dissipation (Max):3.6W (Ta), 104W (Tc)
- Operating Temperature:-55°C ~ 150°C (TJ)
- Mounting Type:Surface Mount
- Supplier Device Package:PQFN (5x6)
- Package / Case:8-PowerTDFN
