PA2247.223NLT
PulseLarsen Antenna
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 22UH 16A 15.8MOHM SMD
- CategoryFixed Inductors
-
ECAD Model
- Share
In Stock: 690
Can ship immediately
Pricing:
- 1$7.54
Quote It
Technical Details
- Series:PA2247.XXXNLT
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:-
- Material - Core:-
- Inductance:22 µH
- Tolerance:±20%
- Current Rating (Amps):16 A
- Current - Saturation (Isat):18A
- Shielding:Unshielded
- DC Resistance (DCR):15.8mOhm Max
- Q @ Freq:-
- Frequency - Self Resonant:-
- Ratings:-
- Operating Temperature:-55°C ~ 125°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.650" L x 0.610" W (16.50mm x 15.50mm)
- Height - Seated (Max):0.394" (10.00mm)
