SPM5015T-1R0M-LR
TDK Corporation
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 1UH 6.3A 24.8 MOHM SMD
- CategoryFixed Inductors
- Datasheet SPM5015T-1R0M-LR Datasheet
-
ECAD Model
- Share
In Stock: 1,197
Can ship immediately
Pricing:
- 1$1.37
- 1,000$0.62688
- 3,000$0.60729
- 5,000$0.5877
- 10,000$0.56811
Quote It
Technical Details
- Series:SPM-LR
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:Metal
- Inductance:1 µH
- Tolerance:±20%
- Current Rating (Amps):6.3 A
- Current - Saturation (Isat):8A
- Shielding:Shielded
- DC Resistance (DCR):24.8mOhm Max
- Q @ Freq:-
- Frequency - Self Resonant:-
- Ratings:-
- Operating Temperature:-40°C ~ 125°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.213" L x 0.201" W (5.40mm x 5.10mm)
- Height - Seated (Max):0.059" (1.50mm)
