SRR4018-120Y
J.W. Miller / Bourns
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 12UH 1.15A 170MOHM SMD
- CategoryFixed Inductors
- Datasheet SRR4018-120Y Datasheet
-
ECAD Model
- Share
In Stock: 917
Can ship immediately
Pricing:
- 1$0.84
- 800$0.2907
- 1,600$0.27455
- 4,000$0.2584
- 5,600$0.2527
Quote It
Technical Details
- Series:SRR4018
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:12 µH
- Tolerance:±30%
- Current Rating (Amps):1.15 A
- Current - Saturation (Isat):900mA
- Shielding:Shielded
- DC Resistance (DCR):170mOhm Max
- Q @ Freq:9 @ 2.52MHz
- Frequency - Self Resonant:32MHz
- Ratings:-
- Operating Temperature:-40°C ~ 125°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:1919 (4848 Metric)
- Supplier Device Package:-
- Size / Dimension:0.189" L x 0.189" W (4.80mm x 4.80mm)
- Height - Seated (Max):0.079" (2.00mm)
