NLV32T-181J-PF

Technical Details

• Series:NLV-PF
• Package:Tape & Reel (TR)Cut Tape (CT)
• Part Status:Not For New Designs
• Type:Wirewound
• Material - Core:Ferrite
• Inductance:180 µH
• Tolerance:±5%
• Current Rating (Amps):60 mA
• Current - Saturation (Isat):-
• Shielding:Unshielded
• DC Resistance (DCR):17Ohm Max

• Q @ Freq:20 @ 796kHz
• Frequency - Self Resonant:7MHz
• Ratings:-
• Operating Temperature:-40°C ~ 105°C
• Inductance Frequency - Test:796 kHz
• Features:-
• Mounting Type:Surface Mount
• Package / Case:1210 (3225 Metric)
• Supplier Device Package:1210
• Size / Dimension:0.126" L x 0.098" W (3.20mm x 2.50mm)
• Height - Seated (Max):0.094" (2.40mm)
