LBC3225T2R2MRV
TAIYO YUDEN
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 2.2UH 930MA 80 MOHM
- CategoryFixed Inductors
- Datasheet LBC3225T2R2MRV Datasheet
-
ECAD Model
- Share
In Stock: 338
Can ship immediately
Pricing:
- 1$0.41
- 1,000$0.41
- 3,000$0.38722
- 5,000$0.36444
- 10,000$0.35306
- 25,000$0.34167
- 50,000$0.33028
Quote It
Technical Details
- Series:LB, C Type
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:-
- Inductance:2.2 µH
- Tolerance:±20%
- Current Rating (Amps):930 mA
- Current - Saturation (Isat):-
- Shielding:Unshielded
- DC Resistance (DCR):80mOhm
- Q @ Freq:-
- Frequency - Self Resonant:190MHz
- Ratings:AEC-Q200
- Operating Temperature:-40°C ~ 105°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:1210 (3225 Metric)
- Supplier Device Package:1210 (3225 Metric)
- Size / Dimension:0.126" L x 0.098" W (3.20mm x 2.50mm)
- Height - Seated (Max):0.106" (2.70mm)
