LQH2MCN1R0M52L
TOKO / Murata
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 1UH 595MA 325 MOHM SMD
- CategoryFixed Inductors
- Datasheet LQH2MCN1R0M52L Datasheet
-
ECAD Model
- Share
In Stock: 233
Can ship immediately
Pricing:
- 1$0.37
- 3,000$0.37
- 6,000$0.34824
- 15,000$0.33735
- 30,000$0.32647
- 75,000$0.31559
Quote It
Technical Details
- Series:LQH2
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:1 µH
- Tolerance:±20%
- Current Rating (Amps):595 mA
- Current - Saturation (Isat):-
- Shielding:Unshielded
- DC Resistance (DCR):325mOhm Max
- Q @ Freq:-
- Frequency - Self Resonant:215MHz
- Ratings:-
- Operating Temperature:-40°C ~ 85°C
- Inductance Frequency - Test:1 MHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:0806 (2016 Metric)
- Supplier Device Package:0806 (2016 Metric)
- Size / Dimension:0.079" L x 0.063" W (2.00mm x 1.60mm)
- Height - Seated (Max):0.037" (0.95mm)
