1264EY-1R5N=P3
TOKO / Murata
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 1.5UH 5.5A 14 MOHM
- CategoryFixed Inductors
- Datasheet 1264EY-1R5N=P3 Datasheet
-
ECAD Model
- Share
In Stock: 1,086
Can ship immediately
Pricing:
- 1$0.46
- 1,500$0.1955
- 3,000$0.184
- 7,500$0.17825
- 10,500$0.1725
- 37,500$0.16675
Quote It
Technical Details
- Series:DG6050C
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:1.5 µH
- Tolerance:±30%
- Current Rating (Amps):5.5 A
- Current - Saturation (Isat):8.3A
- Shielding:Shielded
- DC Resistance (DCR):14mOhm
- Q @ Freq:-
- Frequency - Self Resonant:-
- Ratings:-
- Operating Temperature:-
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.248" L x 0.248" W (6.30mm x 6.30mm)
- Height - Seated (Max):0.197" (5.00mm)
