LQH5BPN2R7NT0L
TOKO / Murata
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 2.7UH 2.5A 35 MOHM SMD
- CategoryFixed Inductors
- Datasheet LQH5BPN2R7NT0L Datasheet
-
ECAD Model
- Share
In Stock: 591
Can ship immediately
Pricing:
- 1$0.46
- 500$0.24129
- 1,000$0.19532
- 2,500$0.18383
- 5,000$0.17809
- 12,500$0.17234
- 25,000$0.1666
- 50,000$0.16085
Quote It
Technical Details
- Series:LQH5
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:2.7 µH
- Tolerance:±30%
- Current Rating (Amps):2.5 A
- Current - Saturation (Isat):3.8A
- Shielding:Shielded
- DC Resistance (DCR):35mOhm
- Q @ Freq:-
- Frequency - Self Resonant:50MHz
- Ratings:-
- Operating Temperature:-40°C ~ 85°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:2020 (5050 Metric)
- Size / Dimension:0.197" L x 0.197" W (5.00mm x 5.00mm)
- Height - Seated (Max):0.087" (2.20mm)
