LQW2BHN6N8D13L
TOKO / Murata
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 6.8NH 1.4A 20 MOHM SMD
- CategoryFixed Inductors
- Datasheet LQW2BHN6N8D13L Datasheet
-
ECAD Model
- Share
In Stock: 484
Can ship immediately
Pricing:
- 1$0.44
- 2,000$0.1755
- 4,000$0.16575
- 6,000$0.156
- 10,000$0.15113
- 50,000$0.14138
Quote It
Technical Details
- Series:LQW2
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:Non-Magnetic
- Inductance:6.8 nH
- Tolerance:±0.5nH
- Current Rating (Amps):1.4 A
- Current - Saturation (Isat):-
- Shielding:Unshielded
- DC Resistance (DCR):20mOhm Max
- Q @ Freq:35 @ 250MHz
- Frequency - Self Resonant:5.4GHz
- Ratings:-
- Operating Temperature:-40°C ~ 85°C
- Inductance Frequency - Test:100 MHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:0805 (2012 Metric)
- Size / Dimension:0.079" L x 0.059" W (2.00mm x 1.50mm)
- Height - Seated (Max):0.070" (1.78mm)
