LQW2BAS43NJ00L
TOKO / Murata
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 43NH 500MA 340 MOHM
- CategoryFixed Inductors
- Datasheet LQW2BAS43NJ00L Datasheet
-
ECAD Model
- Share
In Stock: 333
Can ship immediately
Pricing:
- 1$0.44
- 10$0.38133
- 100$0.27241
- 500$0.22882
- 1,000$0.18524
Quote It
Technical Details
- Series:LQW2
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:Air
- Inductance:43 nH
- Tolerance:±5%
- Current Rating (Amps):500 mA
- Current - Saturation (Isat):-
- Shielding:Unshielded
- DC Resistance (DCR):340mOhm Max
- Q @ Freq:60 @ 500MHz
- Frequency - Self Resonant:1.8GHz
- Ratings:-
- Operating Temperature:-55°C ~ 125°C
- Inductance Frequency - Test:200 MHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:0805 (2015 Metric)
- Supplier Device Package:-
- Size / Dimension:0.082" L x 0.060" W (2.09mm x 1.53mm)
- Height - Seated (Max):0.060" (1.52mm)
