LQH43NN2R2M03L
TOKO / Murata
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 2.2UH 500MA 300 MOHM
- CategoryFixed Inductors
- Datasheet LQH43NN2R2M03L Datasheet
-
ECAD Model
- Share
In Stock: 571
Can ship immediately
Pricing:
- 1$0.57
- 500$0.30072
- 1,000$0.24344
- 2,500$0.22912
- 5,000$0.22196
- 12,500$0.2148
- 25,000$0.20764
Quote It
Technical Details
- Series:LQH43
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:2.2 µH
- Tolerance:±20%
- Current Rating (Amps):500 mA
- Current - Saturation (Isat):-
- Shielding:Unshielded
- DC Resistance (DCR):300mOhm Max
- Q @ Freq:20 @ 1MHz
- Frequency - Self Resonant:62MHz
- Ratings:-
- Operating Temperature:-40°C ~ 105°C
- Inductance Frequency - Test:1 MHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:1812 (4532 Metric)
- Supplier Device Package:1812 (4532 Metric)
- Size / Dimension:0.177" L x 0.126" W (4.50mm x 3.20mm)
- Height - Seated (Max):0.110" (2.80mm)
