SDR0703-151KL
J.W. Miller / Bourns
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 150UH 250MA 2 OHM SMD
- CategoryFixed Inductors
- Datasheet SDR0703-151KL Datasheet
-
ECAD Model
- Share
In Stock: 535
Can ship immediately
Pricing:
- 1$0.75
- 500$0.30346
- 1,000$0.24565
- 2,500$0.2312
- 5,000$0.2261
Quote It
Technical Details
- Series:SDR0703
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:150 µH
- Tolerance:±10%
- Current Rating (Amps):250 mA
- Current - Saturation (Isat):340mA
- Shielding:Unshielded
- DC Resistance (DCR):2Ohm Max
- Q @ Freq:30 @ 796kHz
- Frequency - Self Resonant:9MHz
- Ratings:-
- Operating Temperature:-40°C ~ 125°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.256" L x 0.177" W (6.50mm x 4.50mm)
- Height - Seated (Max):0.106" (2.70mm)
