SRR4018-100Y

J.W. Miller / Bourns
In Stock: 603

Can ship immediately

Pricing:
  • 1$0.84
  • 800$0.2907
  • 1,600$0.27455
  • 4,000$0.2584
  • 5,600$0.2527

Quote It

Technical Details

  • Series:SRR4018
  • Package:Tape & Reel (TR)Cut Tape (CT)
  • Part Status:Active
  • Type:Wirewound
  • Material - Core:Ferrite
  • Inductance:10 µH
  • Tolerance:±30%
  • Current Rating (Amps):1.3 A
  • Current - Saturation (Isat):1A
  • Shielding:Shielded
  • DC Resistance (DCR):150mOhm Max



  • Q @ Freq:10 @ 2.52MHz
  • Frequency - Self Resonant:38MHz
  • Ratings:-
  • Operating Temperature:-40°C ~ 125°C
  • Inductance Frequency - Test:100 kHz
  • Features:-
  • Mounting Type:Surface Mount
  • Package / Case:1919 (4848 Metric)
  • Supplier Device Package:-
  • Size / Dimension:0.189" L x 0.189" W (4.80mm x 4.80mm)
  • Height - Seated (Max):0.079" (2.00mm)
