ELL-ATV180M
Panasonic
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 18UH 2.5A 38 MOHM SMD
- CategoryFixed Inductors
- Datasheet ELL-ATV180M Datasheet
-
ECAD Model
- Share
In Stock: 581
Can ship immediately
Pricing:
- 1$1.57
- 500$0.78318
- 1,000$0.69616
- 2,500$0.6744
- 5,000$0.65265
- 12,500$0.6309
Quote It
Technical Details
- Series:V
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Obsolete
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:18 µH
- Tolerance:±20%
- Current Rating (Amps):2.5 A
- Current - Saturation (Isat):-
- Shielding:Shielded
- DC Resistance (DCR):38mOhm
- Q @ Freq:-
- Frequency - Self Resonant:-
- Ratings:-
- Operating Temperature:-
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.394" L x 0.394" W (10.00mm x 10.00mm)
- Height - Seated (Max):0.177" (4.50mm)
