LQW15AN22NG80D

Technical Details

• Series:LQW15
• Package:Tape & Reel (TR)Cut Tape (CT)
• Part Status:Active
• Type:Wirewound
• Material - Core:Non-Magnetic
• Inductance:22 nH
• Tolerance:±2%
• Current Rating (Amps):780 mA
• Current - Saturation (Isat):-
• Shielding:Unshielded
• DC Resistance (DCR):202mOhm Max

• Q @ Freq:30 @ 250MHz
• Frequency - Self Resonant:4.5GHz
• Ratings:-
• Operating Temperature:-55°C ~ 125°C
• Inductance Frequency - Test:100 MHz
• Features:-
• Mounting Type:Surface Mount
• Package / Case:0402 (1005 Metric)
• Supplier Device Package:-
• Size / Dimension:0.039" L x 0.024" W (1.00mm x 0.60mm)
• Height - Seated (Max):0.024" (0.60mm)
