VLS252012HBX-2R2M-1
TDK Corporation
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 2.2UH 2.3A 102 MOHM
- CategoryFixed Inductors
- Datasheet VLS252012HBX-2R2M-1 Datasheet
-
ECAD Model
- Share
In Stock: 29,923
Can ship immediately
Pricing:
- 1$0.35
- 2,000$0.28152
- 4,000$0.26496
- 6,000$0.25668
- 10,000$0.2484
Quote It
Technical Details
- Series:VLS-HBX-1
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:Metal
- Inductance:2.2 µH
- Tolerance:±20%
- Current Rating (Amps):2.3 A
- Current - Saturation (Isat):2.04A
- Shielding:Shielded
- DC Resistance (DCR):102mOhm Max
- Q @ Freq:-
- Frequency - Self Resonant:-
- Ratings:-
- Operating Temperature:-40°C ~ 105°C
- Inductance Frequency - Test:1 MHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:1008 (2520 Metric)
- Supplier Device Package:1008 (2520 Metric)
- Size / Dimension:0.098" L x 0.079" W (2.50mm x 2.00mm)
- Height - Seated (Max):0.047" (1.20mm)
