SRN4026-2R2Y
J.W. Miller / Bourns
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 2.2UH 2.1A 29 MOHM SMD
- CategoryFixed Inductors
- Datasheet SRN4026-2R2Y Datasheet
-
ECAD Model
- Share
In Stock: 132
Can ship immediately
Pricing:
- 1$0.42
- 3,000$0.136
- 6,000$0.133
Quote It
Technical Details
- Series:SRN4026
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:2.2 µH
- Tolerance:±30%
- Current Rating (Amps):2.1 A
- Current - Saturation (Isat):2.1A
- Shielding:Semi-Shielded
- DC Resistance (DCR):29mOhm Max
- Q @ Freq:9 @ 7.96MHz
- Frequency - Self Resonant:60MHz
- Ratings:-
- Operating Temperature:-40°C ~ 125°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.157" L x 0.157" W (4.00mm x 4.00mm)
- Height - Seated (Max):0.098" (2.50mm)
