SRR1208-180ML
J.W. Miller / Bourns
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 18UH 3.8A 40 MOHM SMD
- CategoryFixed Inductors
- Datasheet SRR1208-180ML Datasheet
-
ECAD Model
- Share
In Stock: 172
Can ship immediately
Pricing:
- 1$1.08
- 400$0.4998
- 800$0.4046
- 1,200$0.3808
- 2,800$0.3724
Quote It
Technical Details
- Series:SRR1208
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:18 µH
- Tolerance:±20%
- Current Rating (Amps):3.8 A
- Current - Saturation (Isat):4A
- Shielding:Shielded
- DC Resistance (DCR):40mOhm Max
- Q @ Freq:21 @ 2.52MHz
- Frequency - Self Resonant:9MHz
- Ratings:-
- Operating Temperature:-40°C ~ 125°C
- Inductance Frequency - Test:1 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.500" L x 0.500" W (12.70mm x 12.70mm)
- Height - Seated (Max):0.335" (8.50mm)
