CM453232-561KL
J.W. Miller / Bourns
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 560UH 50MA 30 OHM SMD
- CategoryFixed Inductors
- Datasheet CM453232-561KL Datasheet
-
ECAD Model
- Share
In Stock: 190
Can ship immediately
Pricing:
- 1$0.38
- 500$0.15182
- 1,000$0.11628
- 2,500$0.10982
- 5,000$0.10336
- 12,500$0.10108
Quote It
Technical Details
- Series:CM45
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:560 µH
- Tolerance:±10%
- Current Rating (Amps):50 mA
- Current - Saturation (Isat):-
- Shielding:Unshielded
- DC Resistance (DCR):30Ohm Max
- Q @ Freq:30 @ 796kHz
- Frequency - Self Resonant:3MHz
- Ratings:-
- Operating Temperature:-40°C ~ 125°C
- Inductance Frequency - Test:796 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:1812 (4532 Metric)
- Supplier Device Package:1812
- Size / Dimension:0.177" L x 0.126" W (4.50mm x 3.20mm)
- Height - Seated (Max):0.134" (3.40mm)
