B82464A4332M000
TDK EPCOS
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 3.3UH 4.9A 15 MOHM SMD
- CategoryFixed Inductors
- Datasheet B82464A4332M000 Datasheet
-
ECAD Model
- Share
In Stock: 202
Can ship immediately
Pricing:
- 1$1.77
- 750$0.99824
- 1,500$0.96705
- 3,750$0.93585
- 5,250$0.90465
Quote It
Technical Details
- Series:B82464A4
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:3.3 µH
- Tolerance:±20%
- Current Rating (Amps):4.9 A
- Current - Saturation (Isat):6.6A
- Shielding:Unshielded
- DC Resistance (DCR):15mOhm Max
- Q @ Freq:-
- Frequency - Self Resonant:100kHz
- Ratings:AEC-Q200
- Operating Temperature:-55°C ~ 150°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.409" L x 0.409" W (10.40mm x 10.40mm)
- Height - Seated (Max):0.189" (4.80mm)
