AIUR-04-272J
Abracon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 2.7MH 100MA 13 OHM TH
- CategoryFixed Inductors
- Datasheet AIUR-04-272J Datasheet
-
ECAD Model
- Share
In Stock: 115
Can ship immediately
Pricing:
- 1$0.2448
- 10$0.2142
- 100$0.153
- 500$0.12852
- 1,000$0.10404
- 2,500$0.09792
Quote It
Technical Details
- Series:AIUR-04
- Package:Bulk
- Part Status:Active
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:2.7 mH
- Tolerance:±5%
- Current Rating (Amps):100 mA
- Current - Saturation (Isat):100mA
- Shielding:Unshielded
- DC Resistance (DCR):13Ohm Max
- Q @ Freq:40 @ 252kHz
- Frequency - Self Resonant:800kHz
- Ratings:-
- Operating Temperature:-25°C ~ 85°C
- Inductance Frequency - Test:252 kHz
- Features:-
- Mounting Type:Through Hole
- Package / Case:Radial, Vertical Cylinder
- Supplier Device Package:-
- Size / Dimension:0.335" Dia (8.50mm)
- Height - Seated (Max):0.441" (11.20mm)
