IMCH1812ER470J
Vishay / Dale
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 47UH 260MA 1.9 OHM SMD
- CategoryFixed Inductors
- Datasheet IMCH1812ER470J Datasheet
-
ECAD Model
- Share
In Stock: 181
Can ship immediately
Pricing:
- 1$0.248
- 5,000$0.248
- 12,500$0.24
- 25,000$0.232
Quote It
Technical Details
- Series:IMCH-1812
- Package:Tape & Reel (TR)
- Part Status:Active
- Type:Wirewound
- Material - Core:-
- Inductance:47 µH
- Tolerance:±5%
- Current Rating (Amps):260 mA
- Current - Saturation (Isat):-
- Shielding:Unshielded
- DC Resistance (DCR):1.9Ohm Max
- Q @ Freq:10 @ 2.52MHz
- Frequency - Self Resonant:11.5MHz
- Ratings:-
- Operating Temperature:-40°C ~ 85°C
- Inductance Frequency - Test:2.52 MHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:1812 (4532 Metric)
- Supplier Device Package:1812 (4532 Metric)
- Size / Dimension:0.177" L x 0.126" W (4.50mm x 3.20mm)
- Height - Seated (Max):0.138" (3.50mm)
