SRU1048A-220Y

J.W. Miller / Bourns
In Stock: 151

Can ship immediately

Pricing:
  • 1$0.5336
  • 2,400$0.4785

Quote It

Technical Details

  • Series:SRU1048A
  • Package:Tape & Reel (TR)Cut Tape (CT)
  • Part Status:Active
  • Type:Wirewound
  • Material - Core:Ferrite
  • Inductance:22 µH
  • Tolerance:±30%
  • Current Rating (Amps):2.6 A
  • Current - Saturation (Isat):2A
  • Shielding:Shielded
  • DC Resistance (DCR):55mOhm Max



  • Q @ Freq:22 @ 2.52MHz
  • Frequency - Self Resonant:12MHz
  • Ratings:AEC-Q200
  • Operating Temperature:-40°C ~ 125°C
  • Inductance Frequency - Test:100 kHz
  • Features:-
  • Mounting Type:Surface Mount
  • Package / Case:Nonstandard
  • Supplier Device Package:-
  • Size / Dimension:0.394" L x 0.394" W (10.00mm x 10.00mm)
  • Height - Seated (Max):0.201" (5.10mm)
