CDRH8D43HPNP-100NC
Sumida Corporation
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 10UH 2.5A 53 MOHM SMD
- CategoryFixed Inductors
- Datasheet CDRH8D43HPNP-100NC Datasheet
-
ECAD Model
- Share
In Stock: 171
Can ship immediately
Pricing:
- 1$0.558
- 500$0.558
Quote It
Technical Details
- Series:CDRH8D43/HP
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:-
- Material - Core:Ferrite
- Inductance:10 µH
- Tolerance:±30%
- Current Rating (Amps):2.5 A
- Current - Saturation (Isat):4.3A
- Shielding:Shielded
- DC Resistance (DCR):53mOhm Max
- Q @ Freq:-
- Frequency - Self Resonant:-
- Ratings:-
- Operating Temperature:-40°C ~ 100°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.315" L x 0.315" W (8.00mm x 8.00mm)
- Height - Seated (Max):0.185" (4.70mm)
