HCMA1104-4R7-R

Technical Details

• Series:HCMA1104
• Package:Tape & Reel (TR)
• Part Status:Active
• Type:Wirewound
• Material - Core:Iron Powder
• Inductance:4.7 µH
• Tolerance:±20%
• Current Rating (Amps):8.5 A
• Current - Saturation (Isat):15A
• Shielding:Shielded
• DC Resistance (DCR):20mOhm Max

• Q @ Freq:-
• Frequency - Self Resonant:-
• Ratings:AEC-Q200
• Operating Temperature:-55°C ~ 125°C
• Inductance Frequency - Test:100 kHz
• Features:-
• Mounting Type:Surface Mount
• Package / Case:Nonstandard
• Supplier Device Package:-
• Size / Dimension:0.437" L x 0.394" W (11.10mm x 10.00mm)
• Height - Seated (Max):0.157" (4.00mm)
