CDRH2D18B/HPNP-6R8NC
Sumida Corporation
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 6.8UH 800MA 241 MOHM
- CategoryFixed Inductors
- Datasheet CDRH2D18B/HPNP-6R8NC Datasheet
-
ECAD Model
- Share
In Stock: 121
Can ship immediately
Pricing:
- 1$0.91295
- 1,000$0.91295
Quote It
Technical Details
- Series:CDRH2D18B/HP
- Package:Tape & Reel (TR)
- Part Status:Active
- Type:-
- Material - Core:Ferrite
- Inductance:6.8 µH
- Tolerance:±25%
- Current Rating (Amps):800 mA
- Current - Saturation (Isat):1.05A
- Shielding:Shielded
- DC Resistance (DCR):241mOhm Max
- Q @ Freq:-
- Frequency - Self Resonant:-
- Ratings:-
- Operating Temperature:-40°C ~ 105°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.126" L x 0.126" W (3.20mm x 3.20mm)
- Height - Seated (Max):0.092" (2.33mm)
