CM322522-221KL
J.W. Miller / Bourns
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 220UH 45MA 21 OHM SMD
- CategoryFixed Inductors
- Datasheet CM322522-221KL Datasheet
-
ECAD Model
- Share
In Stock: 131
Can ship immediately
Pricing:
Call for price or sumbit a RFQ
Quote It
Technical Details
- Series:CM322522
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Obsolete
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:220 µH
- Tolerance:±10%
- Current Rating (Amps):45 mA
- Current - Saturation (Isat):-
- Shielding:Unshielded
- DC Resistance (DCR):21Ohm Max
- Q @ Freq:20 @ 796kHz
- Frequency - Self Resonant:7MHz
- Ratings:-
- Operating Temperature:-40°C ~ 125°C
- Inductance Frequency - Test:796 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.126" L x 0.098" W (3.20mm x 2.50mm)
- Height - Seated (Max):0.087" (2.20mm)
