PM125S-561M-RC
J.W. Miller / Bourns
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 560UH 440MA 1.34OHM SM
- CategoryFixed Inductors
- Datasheet PM125S-561M-RC Datasheet
-
ECAD Model
- Share
In Stock: 145
Can ship immediately
Pricing:
Call for price or sumbit a RFQ
Quote It
Technical Details
- Series:PM125S
- Package:Tape & Reel (TR)
- Part Status:Obsolete
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:560 µH
- Tolerance:±20%
- Current Rating (Amps):440 mA
- Current - Saturation (Isat):740mA
- Shielding:Shielded
- DC Resistance (DCR):1.34Ohm Max
- Q @ Freq:-
- Frequency - Self Resonant:3MHz
- Ratings:-
- Operating Temperature:-40°C ~ 125°C
- Inductance Frequency - Test:1 MHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.496" L x 0.457" W (12.60mm x 11.60mm)
- Height - Seated (Max):0.232" (5.90mm)
