EEU-FC1A102L
Panasonic
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 1000UF 20% 10V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet EEU-FC1A102L Datasheet
-
ECAD Model
- Share
In Stock: 5,594
Can ship immediately
Pricing:
- 1$0.64
- 10$0.448
- 100$0.29531
- 500$0.21874
- 1,000$0.18594
- 2,500$0.17499
- 5,000$0.16406
Quote It
Technical Details
- Series:FC
- Package:Bulk
- Part Status:Active
- Capacitance:1000 µF
- Tolerance:±20%
- Voltage - Rated:10 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:2000 Hrs @ 105°C
- Operating Temperature:-55°C ~ 105°C
- Polarization:Polar
- Ratings:AEC-Q200
- Applications:Automotive
- Ripple Current @ Low Frequency:746.3 mA @ 120 Hz
- Ripple Current @ High Frequency:995 mA @ 100 kHz
- Impedance:65 mOhms
- Lead Spacing:0.138" (3.50mm)
- Size / Dimension:0.315" Dia (8.00mm)
- Height - Seated (Max):0.787" (20.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
