UPJ1A122MPD1TD
Nichicon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 1200UF 20% 10V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet UPJ1A122MPD1TD Datasheet
-
ECAD Model
- Share
In Stock: 1,189
Can ship immediately
Pricing:
- 1$0.76
- 500$0.26319
- 1,000$0.22371
- 2,500$0.21055
- 5,000$0.19739
- 12,500$0.18094
- 25,000$0.17765
- 50,000$0.17107
Quote It
Technical Details
- Series:UPJ
- Package:Cut Tape (CT)Tape & Box (TB)
- Part Status:Active
- Capacitance:1200 µF
- Tolerance:±20%
- Voltage - Rated:10 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:5000 Hrs @ 105°C
- Operating Temperature:-55°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:1.12 A @ 120 Hz
- Ripple Current @ High Frequency:1.28 A @ 10 kHz
- Impedance:78 mOhms
- Lead Spacing:0.197" (5.00mm)
- Size / Dimension:0.394" Dia (10.00mm)
- Height - Seated (Max):1.043" (26.50mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
