UPJ1V391MPD
Nichicon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 390UF 20% 35V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet UPJ1V391MPD Datasheet
-
ECAD Model
- Share
In Stock: 909
Can ship immediately
Pricing:
- 1$0.84
- 10$0.5926
- 100$0.38997
- 500$0.28882
- 1,000$0.2455
- 2,500$0.23105
- 5,000$0.21662
Quote It
Technical Details
- Series:UPJ
- Package:Bulk
- Part Status:Active
- Capacitance:390 µF
- Tolerance:±20%
- Voltage - Rated:35 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:5000 Hrs @ 105°C
- Operating Temperature:-55°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:955 mA @ 120 Hz
- Ripple Current @ High Frequency:1.22 A @ 10 kHz
- Impedance:84 mOhms
- Lead Spacing:0.197" (5.00mm)
- Size / Dimension:0.394" Dia (10.00mm)
- Height - Seated (Max):1.043" (26.50mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
