16TGV820M12.5X13.5
Rubycon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 820UF 20% 16V SMD
- CategoryAluminum Electrolytic Capacitors
- Datasheet 16TGV820M12.5X13.5 Datasheet
-
ECAD Model
- Share
In Stock: 501
Can ship immediately
Pricing:
- 1$1.72
- 200$0.92812
- 400$0.82497
- 600$0.70124
- 1,000$0.61873
- 2,000$0.57748
- 5,000$0.55686
- 10,000$0.53623
Quote It
Technical Details
- Series:TGV
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Capacitance:820 µF
- Tolerance:±20%
- Voltage - Rated:16 V
- ESR (Equivalent Series Resistance):92mOhm @ 100kHz
- Lifetime @ Temp.:5000 Hrs @ 125°C
- Operating Temperature:-40°C ~ 125°C
- Polarization:Polar
- Ratings:AEC-Q200
- Applications:Automotive
- Ripple Current @ Low Frequency:510 mA @ 120 Hz
- Ripple Current @ High Frequency:850 mA @ 100 kHz
- Impedance:-
- Lead Spacing:-
- Size / Dimension:0.492" Dia (12.50mm)
- Height - Seated (Max):0.551" (14.00mm)
- Surface Mount Land Size:0.512" L x 0.512" W (13.00mm x 13.00mm)
- Mounting Type:Surface Mount
- Package / Case:Radial, Can - SMD
