865060562010
Würth Elektronik Midcom
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP 680 UF 20% 35 V
- CategoryAluminum Electrolytic Capacitors
-
ECAD Model
- Share
In Stock: 308
Can ship immediately
Pricing:
- 1$2.65
- 200$2.0752
- 400$1.8562
- 600$1.6382
- 1,000$1.5652
Quote It
Technical Details
- Series:WCAP-ASLL
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Capacitance:680 µF
- Tolerance:±20%
- Voltage - Rated:35 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:5000 Hrs @ 105°C
- Operating Temperature:-55°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:747.5 mA @ 120 Hz
- Ripple Current @ High Frequency:1.15 A @ 100 kHz
- Impedance:66 mOhms
- Lead Spacing:-
- Size / Dimension:0.492" Dia (12.50mm)
- Height - Seated (Max):0.551" (14.00mm)
- Surface Mount Land Size:0.531" L x 0.531" W (13.50mm x 13.50mm)
- Mounting Type:Surface Mount
- Package / Case:Radial, Can - SMD
