450BXW56MEFR18X25
Rubycon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 56UF 20% 450V T/H
- CategoryAluminum Electrolytic Capacitors
- Datasheet 450BXW56MEFR18X25 Datasheet
-
ECAD Model
- Share
In Stock: 215
Can ship immediately
Pricing:
- 1$3.55
- 10$2.87458
- 100$2.19478
- 500$1.67219
- 1,000$1.46317
- 2,500$1.41091
- 5,000$1.35866
Quote It
Technical Details
- Series:BXW
- Package:Bulk
- Part Status:Active
- Capacitance:56 µF
- Tolerance:±20%
- Voltage - Rated:450 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:12000 Hrs @ 105°C
- Operating Temperature:-40°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:560 mA @ 120 Hz
- Ripple Current @ High Frequency:1.4 A @ 100 kHz
- Impedance:-
- Lead Spacing:0.295" (7.50mm)
- Size / Dimension:0.709" Dia (18.00mm)
- Height - Seated (Max):1.063" (27.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
