686AXZ050M
Cornell Dubilier Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 68UF 20% 50V SMD
- CategoryAluminum Electrolytic Capacitors
- Datasheet 686AXZ050M Datasheet
-
ECAD Model
- Share
In Stock: 178
Can ship immediately
Pricing:
- 1$0.20036
- 14,000$0.19125
Quote It
Technical Details
- Series:AXZ
- Package:Bulk
- Part Status:Active
- Capacitance:68 µF
- Tolerance:±20%
- Voltage - Rated:50 V
- ESR (Equivalent Series Resistance):3.413Ohm @ 120Hz
- Lifetime @ Temp.:2000 Hrs @ 105°C
- Operating Temperature:-55°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:175 mA @ 120 Hz
- Ripple Current @ High Frequency:350 mA @ 100 kHz
- Impedance:340 mOhms
- Lead Spacing:-
- Size / Dimension:0.315" Dia (8.00mm)
- Height - Seated (Max):0.417" (10.60mm)
- Surface Mount Land Size:0.327" L x 0.327" W (8.30mm x 8.30mm)
- Mounting Type:Surface Mount
- Package / Case:Radial, Can - SMD
