1718140004
Woodhead - Molex
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN HEADER R/A 4POS 3.96MM
- CategoryRectangular Connectors - Headers, Male Pins
- Datasheet 1718140004 Datasheet
-
ECAD Model
- Share
In Stock: 1,269
Can ship immediately
Pricing:
- 1$0.64
- 10$0.60275
- 100$0.46223
- 500$0.40196
- 1,000$0.33162
- 5,000$0.29142
- 10,000$0.27132
Quote It
Technical Details
- Series:KK396, 171814
- Package:Bulk
- Part Status:Active
- Connector Type:Header
- Contact Type:Male Pin
- Pitch - Mating:0.156" (3.96mm)
- Number of Positions:4
- Number of Rows:1
- Row Spacing - Mating:-
- Number of Positions Loaded:All
- Style:Board to Board or Cable
- Shrouding:Shrouded - 1 Wall
- Mounting Type:Through Hole, Right Angle
- Termination:Solder
- Fastening Type:Friction Lock
- Contact Length - Mating:0.446" (11.33mm)
- Contact Length - Post:0.100" (2.54mm)
- Overall Contact Length:-
- Insulation Height:0.394" (10.00mm)
- Contact Shape:Square
- Contact Finish - Mating:Tin
- Contact Finish Thickness - Mating:60.0µin (1.52µm)
- Contact Finish - Post:Tin
- Contact Material:Brass
- Insulation Material:Polyamide (PA), Nylon
- Features:-
- Operating Temperature:-
- Ingress Protection:-
- Material Flammability Rating:UL94 V-2
- Insulation Color:Black
- Current Rating (Amps):-
- Voltage Rating:-
