2-178841-1
TE Connectivity AMP Connectors
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN HEADER VERT 4POS 6.2MM
- CategoryRectangular Connectors - Headers, Male Pins
- Datasheet 2-178841-1 Datasheet
-
ECAD Model
- Share
In Stock: 2,266
Can ship immediately
Pricing:
- 1$1.66
- 10$1.50451
- 180$1.28935
- 540$1.07446
- 1,080$0.92096
- 5,040$0.81659
- 10,080$0.79816
Quote It
Technical Details
- Series:Universal Power
- Package:Tray
- Part Status:Active
- Connector Type:Header
- Contact Type:Tab
- Pitch - Mating:0.244" (6.20mm)
- Number of Positions:4
- Number of Rows:1
- Row Spacing - Mating:-
- Number of Positions Loaded:All
- Style:Board to Cable/Wire
- Shrouding:Shrouded - 4 Wall
- Mounting Type:Through Hole
- Termination:Kinked Pin, Solder
- Fastening Type:Locking Ramp
- Contact Length - Mating:-
- Contact Length - Post:0.146" (3.70mm)
- Overall Contact Length:-
- Insulation Height:0.563" (14.30mm)
- Contact Shape:Rectangular
- Contact Finish - Mating:Tin
- Contact Finish Thickness - Mating:-
- Contact Finish - Post:Tin
- Contact Material:Copper Alloy
- Insulation Material:Polyamide (PA66), Nylon 6/6
- Features:Board Guide
- Operating Temperature:-30°C ~ 105°C
- Ingress Protection:-
- Material Flammability Rating:UL94 V-0
- Insulation Color:Natural
- Current Rating (Amps):Varies by Wire Gauge
- Voltage Rating:-
