0559321110
Woodhead - Molex- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN HEADER VERT 11POS 2MM
- CategoryRectangular Connectors - Headers, Male Pins
- Datasheet 0559321110 Datasheet
-
ECAD Model
- Share
In Stock: 3,253
Can ship immediately
Pricing:
- 1$0.82
- 10$0.72281
- 100$0.6236
- 500$0.51022
- 1,800$0.42519
- 5,400$0.39684
- 10,800$0.377
Quote It
Technical Details
- Series:MicroClasp 55932
- Package:Tray
- Part Status:Active
- Connector Type:Header
- Contact Type:Male Pin
- Pitch - Mating:0.079" (2.00mm)
- Number of Positions:11
- Number of Rows:1
- Row Spacing - Mating:-
- Number of Positions Loaded:All
- Style:Board to Cable/Wire
- Shrouding:Shrouded - 4 Wall
- Mounting Type:Through Hole
- Termination:Kinked Pin, Solder
- Fastening Type:Latch Holder
- Contact Length - Mating:0.144" (3.66mm)
- Contact Length - Post:0.126" (3.20mm)
- Overall Contact Length:0.360" (9.15mm)
- Insulation Height:0.384" (9.75mm)
- Contact Shape:Square
- Contact Finish - Mating:Tin
- Contact Finish Thickness - Mating:-
- Contact Finish - Post:Tin
- Contact Material:-
- Insulation Material:Polybutylene Terephthalate (PBT)
- Features:Board Guide
- Operating Temperature:-
- Ingress Protection:-
- Material Flammability Rating:-
- Insulation Color:Natural
- Current Rating (Amps):-
- Voltage Rating:-
