1-292132-1
TE Connectivity AMP Connectors
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN HEADER VERT 11POS 2MM
- CategoryRectangular Connectors - Headers, Male Pins
- Datasheet 1-292132-1 Datasheet
-
ECAD Model
- Share
In Stock: 3,796
Can ship immediately
Pricing:
- 1$0.99
- 10$0.87741
- 100$0.7656
- 500$0.63806
- 1,000$0.57426
- 5,000$0.51045
- 10,000$0.48812
Quote It
Technical Details
- Series:CT
- Package:Bulk
- Part Status:Active
- Connector Type:Header
- Contact Type:Male Pin
- Pitch - Mating:0.079" (2.00mm)
- Number of Positions:11
- Number of Rows:1
- Row Spacing - Mating:-
- Number of Positions Loaded:All
- Style:Board to Cable/Wire
- Shrouding:Shrouded - 4 Wall
- Mounting Type:Through Hole
- Termination:Kinked Pin, Solder
- Fastening Type:Detent Lock
- Contact Length - Mating:0.165" (4.20mm)
- Contact Length - Post:0.126" (3.20mm)
- Overall Contact Length:0.358" (9.09mm)
- Insulation Height:0.268" (6.80mm)
- Contact Shape:Circular
- Contact Finish - Mating:Tin
- Contact Finish Thickness - Mating:-
- Contact Finish - Post:Tin
- Contact Material:Brass
- Insulation Material:Polyamide (PA66), Nylon 6/6
- Features:-
- Operating Temperature:-
- Ingress Protection:-
- Material Flammability Rating:UL94 V-0
- Insulation Color:Natural
- Current Rating (Amps):Varies by Wire Gauge
- Voltage Rating:125VAC
