JTN1AS-TMP-F-DC48V
Panasonic
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionRELAY GEN PURPOSE SPST 30A 48V
- Category
- Datasheet JTN1AS-TMP-F-DC48V Datasheet
-
ECAD Model
- Share
In Stock: 122
Can ship immediately
Pricing:
- 1$4.75
- 50$4.75
Quote It
Technical Details
- Series:JT-N
- Package:Bulk
- Part Status:Active
- Mounting Type:Through Hole
- Coil Voltage:48VDC
- Contact Form:SPST-NO (1 Form A)
- Contact Rating (Current):30 A
- Switching Voltage:277VAC - Max
- Coil Current:16.7 mA
- Coil Type:Non Latching
- Features:-
- Termination Style:PC Pin, Quick Connect - 0.250" (6.3mm)
- Seal Rating:Sealed - Fully
- Coil Insulation:Class F
- Must Operate Voltage:36 VDC
- Must Release Voltage:4.8 VDC
- Operate Time:20 ms
- Release Time:10 ms
- Operating Temperature:-55°C ~ 85°C
- Contact Material:Silver Tin Oxide (AgSnO)
- Relay Type:General Purpose
