AOD9T40P
Alpha and Omega Semiconductor, Inc.
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionMOSFET N-CH 400V 6.6A TO252
- CategoryTransistors - FETs, MOSFETs - Single
- Datasheet AOD9T40P Datasheet
-
ECAD Model
- Share
In Stock: 116
Can ship immediately
Pricing:
- 1$0.4774
- 2,500$0.4774
Quote It
Technical Details
- Series:-
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Obsolete
- FET Type:N-Channel
- Technology:MOSFET (Metal Oxide)
- Drain to Source Voltage (Vdss):400 V
- Current - Continuous Drain (Id) @ 25°C:6.6A (Tc)
- Drive Voltage (Max Rds On, Min Rds On):10V
- Rds On (Max) @ Id, Vgs:800mOhm @ 4A, 10V
- Vgs(th) (Max) @ Id:5V @ 250µA
- Gate Charge (Qg) (Max) @ Vgs:18 nC @ 10 V
- Vgs (Max):±30V
- Input Capacitance (Ciss) (Max) @ Vds:530 pF @ 100 V
- FET Feature:-
- Power Dissipation (Max):83W (Tc)
- Operating Temperature:-55°C ~ 150°C (TJ)
- Mounting Type:Surface Mount
- Supplier Device Package:TO-252, (D-Pak)
- Package / Case:TO-252-3, DPak (2 Leads + Tab), SC-63
