- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionMOSFET N-CH 60V 13A/35A TO251A
- CategoryTransistors - FETs, MOSFETs - Single
-
ECAD Model
- Share
In Stock: 166
Can ship immediately
Pricing:
Call for price or sumbit a RFQ
Quote It
Technical Details
- Series:-
- Package:Tube
- Part Status:Obsolete
- FET Type:N-Channel
- Technology:MOSFET (Metal Oxide)
- Drain to Source Voltage (Vdss):60 V
- Current - Continuous Drain (Id) @ 25°C:13A (Ta), 35A (Tc)
- Drive Voltage (Max Rds On, Min Rds On):4.5V, 10V
- Rds On (Max) @ Id, Vgs:16mOhm @ 20A, 10V
- Vgs(th) (Max) @ Id:2.5V @ 250µA
- Gate Charge (Qg) (Max) @ Vgs:30 nC @ 10 V
- Vgs (Max):±20V
- Input Capacitance (Ciss) (Max) @ Vds:1340 pF @ 30 V
- FET Feature:-
- Power Dissipation (Max):6.2W (Ta), 60W (Tc)
- Operating Temperature:-55°C ~ 175°C (TJ)
- Mounting Type:Through Hole
- Supplier Device Package:TO-251A
- Package / Case:TO-251-3 Stub Leads, IPak
