B78148E1101M000
TDK EPCOS
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 100NH 7.3A 15 MOHM TH
- CategoryFixed Inductors
- Datasheet B78148E1101M000 Datasheet
-
ECAD Model
- Share
In Stock: 1,119
Can ship immediately
Pricing:
- 1$0.44
- 2,000$0.1755
- 4,000$0.16575
- 6,000$0.156
- 10,000$0.15113
- 50,000$0.14138
Quote It
Technical Details
- Series:BC+
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:100 nH
- Tolerance:±20%
- Current Rating (Amps):7.3 A
- Current - Saturation (Isat):17A
- Shielding:Unshielded
- DC Resistance (DCR):15mOhm Max
- Q @ Freq:50 @ 7.96MHz
- Frequency - Self Resonant:700MHz
- Ratings:-
- Operating Temperature:-55°C ~ 125°C
- Inductance Frequency - Test:1 MHz
- Features:-
- Mounting Type:Through Hole
- Package / Case:Radial
- Supplier Device Package:-
- Size / Dimension:0.157" Dia (4.00mm)
- Height - Seated (Max):0.453" (11.50mm)
