SRR4028-100Y
J.W. Miller / Bourns
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 10UH 1.19A 110MOHM SMD
- CategoryFixed Inductors
- Datasheet SRR4028-100Y Datasheet
-
ECAD Model
- Share
In Stock: 165
Can ship immediately
Pricing:
- 1$0.84
- 500$0.33916
- 1,000$0.27455
- 2,500$0.2584
- 5,000$0.2527
Quote It
Technical Details
- Series:SRR4028
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:10 µH
- Tolerance:±30%
- Current Rating (Amps):1.19 A
- Current - Saturation (Isat):1A
- Shielding:Shielded
- DC Resistance (DCR):110mOhm Max
- Q @ Freq:11.26 @ 2.52MHz
- Frequency - Self Resonant:34MHz
- Ratings:-
- Operating Temperature:-40°C ~ 125°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:1919 (4848 Metric)
- Supplier Device Package:-
- Size / Dimension:0.189" L x 0.189" W (4.80mm x 4.80mm)
- Height - Seated (Max):0.118" (3.00mm)
