RLB0914-102KL
J.W. Miller / Bourns
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 1MH 420MA 2.1 OHM TH
- CategoryFixed Inductors
- Datasheet RLB0914-102KL Datasheet
-
ECAD Model
- Share
In Stock: 101
Can ship immediately
Pricing:
- 1$0.44
- 10$0.38565
- 100$0.275
- 500$0.231
- 1,000$0.187
- 2,500$0.176
Quote It
Technical Details
- Series:RLB
- Package:Bulk
- Part Status:Active
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:1 mH
- Tolerance:±10%
- Current Rating (Amps):420 mA
- Current - Saturation (Isat):650mA
- Shielding:Unshielded
- DC Resistance (DCR):2.1Ohm Max
- Q @ Freq:40 @ 252kHz
- Frequency - Self Resonant:1.3MHz
- Ratings:-
- Operating Temperature:-40°C ~ 105°C
- Inductance Frequency - Test:252 kHz
- Features:-
- Mounting Type:Through Hole
- Package / Case:Radial, Vertical Cylinder
- Supplier Device Package:-
- Size / Dimension:0.343" Dia (8.70mm)
- Height - Seated (Max):0.512" (13.00mm)
