NRH2410T220MN

Technical Details

• Series:NR, H Type
• Package:Tape & Reel (TR)Cut Tape (CT)
• Part Status:Active
• Type:Wirewound
• Material - Core:Ferrite
• Inductance:22 µH
• Tolerance:±20%
• Current Rating (Amps):300 mA
• Current - Saturation (Isat):390mA
• Shielding:Shielded
• DC Resistance (DCR):1.764Ohm Max

• Q @ Freq:-
• Frequency - Self Resonant:22MHz
• Ratings:-
• Operating Temperature:-25°C ~ 120°C
• Inductance Frequency - Test:100 kHz
• Features:-
• Mounting Type:Surface Mount
• Package / Case:Nonstandard
• Supplier Device Package:-
• Size / Dimension:0.094" L x 0.094" W (2.40mm x 2.40mm)
• Height - Seated (Max):0.039" (1.00mm)
