L04022R7AHN
Elco (AVX)
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 2.7NH 250MA 250 MOHM
- CategoryFixed Inductors
- Datasheet L04022R7AHN Datasheet
-
ECAD Model
- Share
In Stock: 200
Can ship immediately
Pricing:
- 1$0.2604
- 5,000$0.2604
Quote It
Technical Details
- Series:Accu-L® 0402
- Package:Tape & Reel (TR)
- Part Status:Active
- Type:Thin Film
- Material - Core:Non-Magnetic
- Inductance:2.7 nH
- Tolerance:±0.05nH
- Current Rating (Amps):250 mA
- Current - Saturation (Isat):-
- Shielding:Unshielded
- DC Resistance (DCR):250mOhm Max
- Q @ Freq:15 @ 450MHz
- Frequency - Self Resonant:9.5GHz
- Ratings:-
- Operating Temperature:-
- Inductance Frequency - Test:450 MHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:0402 (1005 Metric)
- Supplier Device Package:0402 (1005 Metric)
- Size / Dimension:0.039" L x 0.023" W (1.00mm x 0.58mm)
- Height - Seated (Max):0.018" (0.45mm)
