SRP5030TA-3R6M

Technical Details

• Series:SRP5030TA
• Package:Tape & Reel (TR)
• Part Status:Active
• Type:Wirewound
• Material - Core:Carbonyl Powder
• Inductance:3.6 µH
• Tolerance:±20%
• Current Rating (Amps):4.9 A
• Current - Saturation (Isat):7A
• Shielding:Shielded
• DC Resistance (DCR):4.9mOhm Max

• Q @ Freq:15 @ 100kHz
• Frequency - Self Resonant:29MHz
• Ratings:AEC-Q200
• Operating Temperature:-40°C ~ 150°C
• Inductance Frequency - Test:100 kHz
• Features:-
• Mounting Type:Surface Mount
• Package / Case:Nonstandard
• Supplier Device Package:-
• Size / Dimension:0.205" L x 0.110" W (5.20mm x 2.80mm)
• Height - Seated (Max):0.118" (3.00mm)
